Product Description:

industrial Gas Alarm Controller

Adopts the original Swiss imported sensor

Standard with 3-wire 4-20mA analog signal output.

Relay output, RS485 output (optional)

Unique infrared remote control function, non-contact operation and maintenance of the instrument.

Compatible with various control alarms, PLC, DCS and other control systems.

Remote monitoring can be realized.

Explosion-proof design, fast, reliable and stable; explosion-proof grade is Exd II CT6.

Full software auto-calibration function, the machine is set up with standard three keys to realize single-person single-point on-site maintenance.

Specifications:
Detection gas: VOG
Detection Principle: PID Ion Detection Principle
Measuring range: 0-2000ppm; Resolution: 1ppm; Accuracy: ±5% F.S or ±10% (depending on specific gas type)
Response time: ≤60S
Output Signal: 4-20mA and RS485 Output(optional)
Repeatability: ≤±1%
Zero drift: ≤±1%
Operating Temperature: -20℃～+55℃
Explosion-proof grade: Ex d II CT6
Power supply: 12-24V DC
Dimension: 180×150×90mm
Recovery Time: ≤10S
Linearity Error: ≤±1%
Display Technology: High brightness digital tube display
Pipe Thread Size: M45*2mm
Operating humidity: 0-95%RH
Protection class: IP65
Working time: 24hours
Weight: ≤1.6kg
