  • VTSYIQI Portable Vibration Calibrator Vibration Meter Calibrator Vibrometer Calibrator for Quick and Easy Checking of Accelerometers Vibration Monitoring Systems Recording Systems

VTSYIQI

VTSYIQI Portable Vibration Calibrator Vibration Meter Calibrator Vibrometer Calibrator for Quick and Easy Checking of Accelerometers Vibration Monitoring Systems Recording Systems

$54600
In stock
$54600

Introduction:

The Vibration Calibrator is a small, self-contained handheld shaker designed for quick and easy checking of accelerometers, vibration monitoring systems and recording systems.

Applications:

* The Vibration Calibrator is a small, self-contained handheld shaker designed for quick and easy checking of accelerometers, vibration monitoring systems and recording systems.

Providing a known and controlled RMS vibration for verification of accelerometers weighing up to 150g.

Features:

* Operates at 159.2 Hz.

* 10 mm/s RMS velocity output.

* Drives vibration sensors up to 150g.

CE compliant.

Specification:

Operating Frequency：159.2 Hz ± 0.5 %

* Acceleration Output：10 m/s² (RMS) ± 3%

* Velocity Outout: 10mm/s(RMS)±3%

* Displacement Output: 10um(RMS)±3%

* Transverse Output: <5%

* Distortion: <3%

* Maximum Losd: 150 g

* Ramp-Up Time: < 3 Seconds

* Operating Conditions：Temp: -10~40°C   Humidity: <85%RH

* Battery Supply: 4x1.5V AA (UM-3) battery (Battery not included in the package)

* Size (Diamter x Height)：56 mm x 200 mm

* Weight (with batteries)：900 g

* Standard Accessories: Main Unit, Carrying Case, Manual Book
