Product performance

1. ARM Cortex™-A7 architecture processor, 7-inch touch screen

2. Integrated spectrophotometric detection module

3. DC 12V power supply, can be connected to vehicle power supply.

4. Single wavelength cold light source, each channel supports 4 detection wavelengths

5. Light source calibration

6. Pulsed constant current drive to avoid light decay and temperature drift caused by continuous lighting.

7. Built-in Pinyin input method, which can edit Chinese and English information.

8. Built-in common sample database, which can be added continuously.

9. Uninterrupted sample injection, continuous detection

10. The sample number is automatically accumulated.

11. Standard USB interface, driver-free installation.

12. The test results can be printed in batches

15. The test result is an Excel table, which can be directly copied to the U disk.

16. The storage capacity of test results is 5 million

17. High-speed thermal printer, the test report can be automatically printed after the test is completed.

Scope of application
 This instrument is suitable for food safety testing in farmers' markets, agricultural testing centers, supermarkets, school restaurants and related regulatory authorities.

Product Application:

Acid Value and Peroxide Value Analyzer is an integrated rapid testing device for oil products, capable of swiftly detecting acid value and peroxide value content in edible vegetable oils, lard, peanut oil, sunflower oil, rice bran oil, foodstuffs, and meat products. Testing determines whether vegetable oils meet national standards or identify substandard oils, including recycled cooking oil. The instrument reserves additional testing programs and ports, allowing for convenient independent expansion of testing capabilities based on future needs. It can be upgraded to a comprehensive instrument for testing aquatic products and flour-based foods.

Basic parameters
Absorbance range: 0~3.5(OD)
Sensitivity: 0.01(OD)
Single hole repeatability: ≤±0.01(OD)
Channel difference: ≤±0.08(OD)
External power supply: DC12V /2A
Rated power: 8W
Repeatability: CV≤5%
Stability: CV≤5%

Storage conditions
The surface of the instrument should be cleaned before long-term storage. After packaging, it should be stored in an ambient temperature of -10℃～40℃, atmospheric pressure (86～106) kPa, relative humidity not exceeding 85%, no condensation, no corrosive gas and good ventilation within the environment.

Configuration List

Instrument Host       1
Power Adapter      1
Thermal Printing Paper     1
User's Manual      1
Certificate      1
