About this item

High level of intelligence, Chinese menu design. Test immediately upon startup, without the need for intermediate process parameter interpretation. Digital display of crack depth value directly The universal calibration ruler ensures the accuracy of the distance between measuring points Improved the detachment of crack depth testing

Product Application The crack depth tester does not need to calibrate the sound velocity and only needs to perform two-point cross crack testing. Directly display the depth of the crack. Greatly improved detection efficiency.

Technical index instrument Specialized on-site crack depth testing calibration ruler Ensured the accuracy of the distance between measuring points Crack depth testing range:<_ 500mm

Test error: When the crack depth is less than 50mm, the test error is 5mm; When the crack depth is greater than (or equal to) 50mm. test error 10% of the actual seam depth;

Test data storage capacity: 25000 test data Data transmission connection Q: USB and RS232

Product Characteristics

.Highly intelligent with Chinese menu interface. Ready to measure upon startup—no need to interpret intermediate process parameters. Digital display directly shows crack depth values.

.Universal calibration gauge ensures accurate measurement point spacing, enhancing crack depth testing precision.

Product Application.

The Crack Depth Tester requires no sound velocity calibration—only a two-point crack span test. Directly displays crack depth, significantly boosting inspection efficiency.

Technical Specifications.

Dedicated field calibration gauge ensures precise measurement point spacing..

Crack depth measurement range: <500mm

.Testing error:

For cracks <50mm deep: testing error ≤5mm;

For cracks ≥50mm deep: testing error ≤10% of actual crack depth;

.Test data storage capacity: 25,000 test entries

.Data transmission interfaces: USB and RS232
