About this item:

1.Big Aperture----8MM

2.SCI/SCE----It supports both SCI and SCE test which is more consistent with result of visual method.

3.Many different kinds of test parameters----Opacity, whiteness index, yellowness index and other 30 kinds of test parameters

4.Portable and Massive Color Card Database----Connect to mobile phone APP to create database to upload the color shades from printing, paint, textile color cards. No need to carry big and heavy color card, we can find color card database from Colormeter Pro APP and find the closed/similar color easier and faster.

5.Better performance than traditional colorimeter----1). UV for fluorescence material test; 2). Camera to see the test area to avoid test error; 3). Paint color matching software: user can use mobile phone App to achieve color correction function.

Introduction:

Spectral colorimeter series develops new color measurement method of colorimeter with build-in camera to see test area, UV light source for fluorescence color measurement, connected to mobile phone APP, unlimited storage memory, build-in color cards to find the similar color at anytime and anywhere. User can also use APP for color matching and color correction.

Features:

1. Different apertures: Big Aperture 8MM
2. Auto calibration
3. SCI/SCE:It supports both SCI and SCE test which is more consistent with result of visual method.
4. Many different kinds of test parameters:Opacity, whiteness index, yellowness index and other 30 kinds of test parameters
5. Provide 26 Kinds of Illuminants for Choice
6. Good repeatability for stable measurement (Delta E*ab 0.08)
7. Portable and Massive Color Card Database:Connect to mobile phone APP to create database to upload the color shades from printing, paint, textile color cards. No need to carry big and heavy color card, we can find color card database from Colormeter Pro APP and find the closed/similar color easier and faster.
8. Cloud database, more convenient to view and upload:Official color card databases are available. Personal users can update color information to cloud and share between different instruments which make color management much easier. Enterprise users can create and manage their own color library and formula information in the cloud and share the information to their customers and suppliers through the unique invitation code.
9. Better performance than traditional colorimeter:

1). UV for fluorescence material test;

2). Camera to see the test area to avoid test error;

3). Paint color matching software: user can use mobile phone App to achieve color correction function.

Technical Specifications:

Color:Dark Blue

Geometry:D/8 (diffused illumination,8 degree viewing),SCI (specular component included),SCE (specular component excluded)

Repeatability:Chromaticity Value:Standard deviation ΔE*ab≤ 0.03;Average : dE*ab≤ 0.04;Max.: dE*ab≤ 0.06;(when a white tile is measured 30 times at 5 seconds interval)

Inter-instrument Agreement:ΔE*ab≤0.4

Display Accuracy:0.01

Test Aperture:Φ8mm

Color Space and Indices:Reflectance, CIE-Lab, CIE-LCh, Hunter Lab, CIE-Luv, XYZ, Yxy, RGB, Color Difference (ΔE*ab, ΔE*cmc, ΔE*94, ΔE*00), Whiteness Index (ASTM E313-00, ASTM E313-73, CIE/ISO, AATCC, Hunter, Taube Berger Stensby), Yellowness Index(ASTM D1925, ASTM E313-00, ASTM E313-73), Blackness Index(My,dM), Staining Fastness, Color Fastness, Tint(ASTM E313-00), Color Density CMYK(A,T,E,M), Metamerism Index Milm, Munsell, Opacity, Color Strength

Illuminants:A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84

Support Color Matching Software:Support color matching on APP( if user buy the color matching software)

Light Source:LED+UV

Camera:Yes

Calibration:Auto

Software:Android, IOS, Windows

Observer:2°，10°

Sphere Size:40mm

Standard:Conform to CIE No.15，GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7

Spectroscopic Method:Integrated optics

Sensor:CMOS Sensor

Wavelength interval:10nm

Wavelength:400-700nm

Reflectance:0-200%

Reflectance Resolution:0.01%

Measurement Time:About 1 second

Interface:USB, bluetooth

Screen:IPS full color screen ,2.4 inches

Battery:Rechargeable, 8,000 times continuous tests, 3.7V/3000mAh

Light Source:10 years, 1 million tests

Language:Chinese and English

Storage:APP Mass Storage
