About this item

◆ Max load:500N/50kg, Min load:50N/5kg; The NK series are dial force gauge with compact size and high accuracy.

◆ Load graduation value:2.5 N/500 g; They are easy to operate and handy to carry out.

◆ Rod journey: 10 mm; Needle indicates, easy to read, Work environment: No vibrancy and no cautery

◆ Two kind of unit Newton and Kilogram dual unit show at the same time,don't need unit conversion.

◆ Widely applied in rubber plastic, light industry, textile, building windows and doors, compound materials, electric wire and cable, auto part, power generator, scientific research institute to do the push pull force insertion force and destructive experiment.

Product Description

The force gauge series are dial force gauge with compact size and high accuracy.

They are easy to operate and handy to carry out. Widely applied in rubber plastic, light industry, textile, building windows and doors, compound materials, electric wire and cable, auto part, power generator, scientific research institute to do the push pull force insertion force and destructive experiment.

Technical Specifications

* Max load:500N/50kg

* Min load:50N/5kg

* Load graduation value:2.5 N/500 g

* Rod journey: 10 mm

* Work temperature: 20°土10℃

* Working temperature: -27℃~+70℃, Relative humidity: 15%~80%RH

* Work environment: No vibrancy and no cautery

* Size: 260 * 66 * 36 (mm)

Character

* With easy operation

* Peak holding function and continuous.

* Compact and artistic packing, easy to transit and stock.

* Two kind of unit dual show at the same time,don't need unit conversion.

* Unit: Newton and Kilogram dual unit;

* Needle indicates, easy to read, high accuracy
