* The instrument is a kind of portable measuring instrument; it can be quickly, nondestructive and high accuracy when measuring common metal materials hardness. It can be used in the laboratory, as well as the on-site engineering field. It can meet the needs of a variety of measurement through instrument measuring conditions setting.

Application

* Bearings and other parts;

* Failure analysis of pressure vessel, steam turbine generator group and equipment;

* Heavy workpieces;

* Mechanical or permanent assembly installed;

* The test space is very narrow;

* The original record of formal requirements on test results;

Features

* Intelligent simple: easy operation, directly shows Leeb scale and Rockwell values

* Small and portable: Small, portable instrument, integrated design without connecting cables, improves the reliability

* Industry highlights, OLED display: Can clear display data under direct sunlight, suitable for all kinds of lighting conditions

* Accurate Measurement: High precision of measurement circuit value error for ±0.5%(HLD=800),repetition rate value for 0.8%

* Support for multiple hardness standard: HL、HV、HRA、HRC、HRB、HB、HS

* Massive capacity data storage: The unprecedented mass storage leads the technology trend. It can save 270hardness measurement data, each group including average, hardness standard.

Technical Specifications

* Testing direction:Highly accurate in any impact direction

* Testing Range:(170-960)HLD,(17.9-69.5)HRC,,(19-683)HB,(80-1042)HV,(30.6-102.6)HS,(59.1-88)HRA,(13.5-101.7)HRB

* Hardness Standards:HL、HV、HRA、HRC、HRB、HB、HV、HS

* Accuracy:HLD：±0.5% (800HLD)

* Repeatability Value:HLD：0.8% (800HLD)

* Resolution:128×64 OLED display

* Dimensions:148mm×40mm×30mm

* Power Supply:Rechargeable lithium battery

* Working Hours:About 10 hours

* Operating temperature: 10-50 c;

* Storage temperature: -30 ℃ -60 ℃; Humidity: 90% max;
