  • VTSYIQI Lab Color Meter Colorimeter Color Difference Chromatic Value with Caliber 8mm 1.14inches Full Color Screen Display Auto Calibration for Plastics Printing Packaging Textile Clothing

VTSYIQI

VTSYIQI Lab Color Meter Colorimeter Color Difference Chromatic Value with Caliber 8mm 1.14inches Full Color Screen Display Auto Calibration for Plastics Printing Packaging Textile Clothing

$22600
有货
$22600

Customer Service

Post your customer service details here.

Return Policy

Post your policy conditions details here.

VTSYIQI  Lab Color Meter Colorimeter Color Difference Chromatic Value with Caliber 8mm 1.14inches Full Color Screen Display Auto Calibration for Plastics Printing Packaging Textile Clothing

About this item

Adopt international used D/8 (Diffused Illumination, 8 degree viewing) geometry and SCI mode to make measurement more accurate

Adopt spectral sensor to provide reflectance data which make its performance is nearly same as spectrophotometer

To get correct LCIE-Lab, ΔE*ab and reflectance curve under light source D65 or D50

Pass or fail judgment can be seen directly from the screen to make color QC much easier

It can connect with mobile phone APP to create database to upload the color shades from printing, paint, textile color cards.

Description

It is the basic model of the ColorMeter series, which can meet the basic color test requirement, but it is different from the traditional colorimeter. It adopts the geometry of D/8 which is same as spectrophotometer, small size to make it more convenient to use; the instrument can be wirelessly connected with Android or IOS devices, and the color can be managed from the mobile phone APP; it has the function of finding the closet color to find the color you want. It is widely used for color control in plastics, printing, packaging, textile, clothing and other industries

Specification

Geometry:D/8 ,Specular Component Included（SCI）

Color Spaces and Indices:CIE-Lab,ΔE*ab, reflectance curve

Light Source:LED(Full Wavelength Balanced LED Light Source)

Measure Aperture:8mm

Repeatability:ΔE≤0.1(when a white tile is measured 30 times at 5-second intervals after calibration)

Measurement Time:1.5s

Interface:USB (only for charging)

Illuminants:D65

Observer:10°

Screen:IPS Full Color Screen（135*240,1.14inch）

Battery:4.2V/500mAh，Rechargeable, 5,000 continuous tests

Language:English and Chinese

Calibration:Auto

Software Support：Android , IOS

Weight：About 90g

Instrument Size：Diameter 31mm，Height 102mm
