VTSYIQI Screen Tension Gauge Digital Screen Printing Tension Meter with Measurement Range 7~40N/cm Resolution 0.1 Fiducial Error 5% for Screen Tension and Stencil Tension Measurements

About this item:

Measurement Range 0~60 N/cm Suitable for general wire mesh tension and steel mesh tension measurement.

Display Range: 0~50N/cm Suitable for screen printing and screen stencil measurement, high accuracy. The ideal and necessary tool for production of precise screen and steel mesh. Can avoid the personal or tactile measurement error.

Resolution 0.1, Fiducial Error: 5% LCD digital display, eliminating reading error.

LCD digital display, eliminating reading error Data in the table is based on testing condition of Swiss thick gauze. Concrete data depends on the quality of network machine. With good quality network machine

Suitable for general wire mesh tension and steel mesh tension measurement. the gauze will not crack even in the highest tension. but if it exceeds the maximum tension, the gauze crackes easily, please reference when trapping net

Application:

Suitable for general wire mesh tension and steel mesh tension measurement.

Suitable for screen printing and screen stencil measurement, high accuracy. The ideal and necessary tool for production of precise screen and steel mesh. Can avoid the personal or tactile measurement error.

LCD digital display, eliminating reading error

Specification:

Measurement Range 7~40 N/cm

Resolution 0.1

Operating Environment Temperature: 0 ~ 40 C Humidity: 10 ~ 90 RH

Power Supply 4 x 1.5 V AAA Size (UM-4) Battery

Demensions 175 x 95 x 40 mm

Weight 490 g (Not Including Batteries)
