VTSYIQI Three-Angle Spectrophotometer Digital Three Angle Colorimeter Portable Three Angle Color Meter with Spectral Range 400-700nm Color Angle 15° 45° 110° for Laser Paper and Mobile Phone Back Shell Measurement

VTSYIQI Three-Angle Spectrophotometer Digital Three Angle Colorimeter Portable Three Angle Color Meter with Spectral Range 400-700nm Color Angle 15° 45° 110° for Laser Paper and Mobile Phone Back Shell Measurement

Introduction:

Different viewing angles and viewing conditions can change the overall color impression of a topcoat. The Multi-Angle Effect Colorimeter cs-390 combines various functions in one handheld instrument to measure multi-angle color differences. It is a multi-angle color measurement instrument developed specifically for the automotive paint industry. It is suitable for measuring reflection spectra and color data of automotive surface paint.
The CS-392 also adds a function to measure the color of special particles and can detect the characteristics of coated aluminum foil.

Feature:

Illumination angle:45°

Measuring angle:Color angle：15°、45°、110°

Particle angle: integral sphere diffusion

Measurement parameters:Color parameters: L * a * b *, de * ab

Particle parameter: particle grade (g)

Spectral range:400-700nm

Spectral interval:10nm

Measuring range:0-500%

Resolving power:0.01%

Lighting source:LED

Measuring time:Less than 5 seconds.

Repeatability:De ≤ 0.05 (measure white board 30 times, interval 5 seconds)

Inter station error:De ≤ 0.5 (measure the average value of BCRA standard plate)

Measurement area:Diameter 17mm

Observation angle:2° and 10°

Lighting source:A、C、D50、D65、F2、F7、F11 & F12

Support language:Chinese, English, French, German, Russian

Industry standard:DIN 6175

Interface:USB, Bluetooth, WiFi optional

Parameter:About145*58*99mm

Weight:500g

Power Supply:3.7v/3000mah rechargeable lithium battery

Service temperature:0-40℃

Storage temperature:-20℃ - 50℃
